SQUARE D SCHNEIDER EZM3800CBU 800 AMP 3 PHASE EZM METER MAIN CIRCUIT BREAKER EUSERC

SQUARE D SCHNEIDER EZM3800CBU 800 AMP 3 PHASE EZM METER MAIN CIRCUIT BREAKER EUSERC

$11,899.00 USD
$11,899.00 USD
Sale Sold out
Square D EZM3800CBU 3 Phase EZM Meter Stack Main Circuit Breaker. EUSERC. This main circuit breaker unit can be feed from underground service only. This EZ Meter Pak has a 3P 800 A main circuit breaker with a 65 kA short circuit current rating. The rated operational voltage is 208Y/120 V AC or 240/120 VAC delta. The unit has an aluminum bus bar. The main is rated 800 A. Line phase and neutral lug landing pads are provided for use with Crimp type lugs. Each landing pad will accept 2 lugs. The lugs must be ordered separately. This unit has a NEMA 3R surface mounting enclosure that is 69.03 inches tall, 20.46 inches wide and 11.50 inches deep. This main circuit breaker unit is UL Listed.

Note:

1. Though this is a brand-new item, and, we will add additional carton outside its original manufactory's carton packing. Due to its heavy weight and potential long transportation.  Some minor cosmetic imperfections might occur, such as minor scratches, tiny paint offs etc.  By ordering this item, you agree to accept those potential minor cosmetic imperfections if any, in which will not affect to its operational functionalities.

2. Item will be shipped with insurance and signature required. Please make sure someone will be at destination address to exam and sign the package.

3. If you are not sure, please consult serving utility for their requirements prior to ordering and installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must comply with all national and local codes, laws and regulations. By ordering this item, you acknowledge that you already done your due diligence, fully understand installation requirements, confirmed with power/utility company and inspector for their approvals or fully understand the risks if you haven't done that yet and willing to take risk on your own.

View full details
