SQUARE D SCHNEIDER EMT3225CB 225A METER MAIN COMBO 3 PHASE 4W w/ BYPASS EUSERC

SQUARE D SCHNEIDER EMT3225CB 225A METER MAIN COMBO 3 PHASE 4W w/ BYPASS EUSERC

$3,999.00 USD
$3,999.00 USD
Sale Sold out
Square D Schneider EMT3225CB 225A ring type meter main combo. 3 phase 4 wire 7 jaw/terminal with test block bypass.

Individual meter main with test block bypass meets EUSERC requirements. This individual meter socket is designed for 3 phase 4W incoming system and outgoing service. The rated operational voltage is 208Y/120 VAC or 240/120 VAC Delta. The meter socket can be feed from an overhead or underground service. This individual meter socket has a ringed socket with 7 jaws. The meter socket is rated 200 A. The lugs will accept 6 AWG to 300 kcmil copper or aluminum wire. This unit has a NEMA 3R flush mounting enclosure that is 30.00 inches tall, 22.44 inches wide and 7.50 inches deep. This Individual meter main with test block bypass is UL listed.

Note:

1. Though this is a brand-new item, and, we will add additional carton outside its original manufactory's carton packing. Due to its heavy weight and potential long transportation.  Some minor cosmetic imperfections might occur, such as minor scratches, tiny paint offs etc.  By ordering this item, you agree to accept those potential minor cosmetic imperfections if any, in which will not affect to its operational functionalities. Any physical damage needs to be reported within 24 hours of receiving.

2. Item will be shipped with insurance and signature required. Please make sure someone will be at destination address to exam and sign the package.

3. If you are not sure, please consult serving utility for their requirements prior to ordering and installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must comply with all national and local codes, laws and regulations. By ordering this item, you acknowledge that you already done your due diligence, fully understand installation requirements, confirmed with power/utility company and inspector for their approvals or fully understand the risks if you haven't done that yet and willing to take risk on your own.
