Square D

SQUARE D EZMT332225 3 PH 1200A bus 2-Gang 7J 225A EZM Meter Stack w/ Test Block Bypass

SQUARE D EZMT332225 3 PH 1200A bus 2-Gang 7J 225A EZM Meter Stack w/ Test Block Bypass

Regular price $5,999.00 USD
Regular price Sale price $5,999.00 USD
Sale Sold out
3 Phase In and 3 Phase Out.
This branch unit is ringed and rated 225A. It has 2 seven jaw sockets for use. The system voltage is 208Y/120 VAC and a test block bypass. It includes a 1200 A aluminium/copper busbar. It is compliant with UL standards and the steel enclosure has a rating of NEMA 3R.

Note:

1. Though this is a brand-new item, and, we will add additional carton outside its original manufactory's carton packing. Due to its heavy weight and potential long transportation.  Some minor cosmetic imperfections might occur, such as minor scratches, tiny paint offs etc.  By ordering this item, you agree to accept those potential minor cosmetic imperfections if any, in which will not affect to its operational functionalities.

2. Item will be shipped with insurance and signature required. Please make sure someone will be at destination address to exam and sign the package.

3. If you are not sure, please consult serving utility for their requirements prior to ordering and installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must comply with all national and local codes, laws and regulations. By ordering this item, you acknowledge that you already done your due diligence, fully understand installation requirements, confirmed with power/utility company and inspector for their approvals or fully understand the risks if you haven't done that yet and willing to take risk on your own.
