SQUARE D

SQUARE D EZM31200GCBEMS 1200 AMP 3 PH 4-WIRE EZM MAIN CIRCUIT BREAKER EUSERC

SQUARE D EZM31200GCBEMS 1200 AMP 3 PH 4-WIRE EZM MAIN CIRCUIT BREAKER EUSERC

Regular price $22,999.00 USD
Regular price Sale price $22,999.00 USD
Sale Sold out
Square D EZM31200GCBEMS 3 phase 1200A main circuit breaker in original manufactory box.

This main circuit breaker provides 3 phases in, 3 phases out for a 4 wire configuration. It accepts 208Y/120VAC and 240/120VAC delta incoming service from UG feeds. The unit is rated for 1200A with the busbar rated for 1200A. With ERMS (energy reducing maintenance switch), it has a short circuit current rating of 65kA. The enclosure is painted steel Type 3R. This EZ Meter-Pak meter center complies with UL and EUSERC standards.

Note:

1. Though this is a brand-new item, and, we will add additional protection outside its original manufactory's carton packing. Due to its heavy weight and potential long freight transportation.  Some minor cosmetic imperfections might occur, such as minor scratches, tiny paint offs etc.  By ordering this item, you agree to accept those potential minor cosmetic imperfections if any, in which will not affect to its operational functionalities.

2. Item will be shipped with insurance and signature required. Please make sure someone will be at destination address to exam and sign the package. Flat Freight rate apply to the lower 48 states only.  Contact me for the shipping if out side of lower 48 states.

3. If you are not sure, please consult serving utility for their requirements prior to ordering and installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must comply with all national and local codes, laws and regulations. By ordering this item, you acknowledge that you already done your due diligence, fully understand installation requirements, confirmed with power/utility company and inspector for their approvals or fully understand the risks if you haven't done that yet and willing to take risk on your own.
